NKC42 Network Converter
The NKC42 is a universal adapter that allows one to connect the existing analog fuel, fresh water, waste water, live well, oil, black water sensors to the NMEA 2000 network.
Description & Features
NKC series attaches directly into J1939 and NMEA 2000 networks of comparable engines, transmissions and gen-sets and converts the signals to the NMEA 2000 or J1939 CAN bus data
J1939 & NMEA 2000 output for use with on board device
NKC series can be used to get engine data, tank levels, alarm status, generic pressure and temperature indications from any resistive sensors
Programmable sensor types including fuel, fresh water, waste water, live water, oil, and black water
Programmable sensor number up to 16 per sensor type
Adapts American standard (240~33 ohm) or European standard (0~190 khm) resistive sensors to NMEA 2000 network.
NMEA 2000 interface
Specifications:
Item No.: 4 Channels JKE00233
Dimensions: NKC 70*Ø27mm
Protection Rating: IP67
Signal Output: NMEA 2000/J1939 Network Messages
Operating Voltage: 8~32V
Connector: Male “Micro-C” Pinout
Operation Temperature: -40°F ~ +185°F(-40°C~+85°C)
Mac Current: 50mA
