Cajun Anchor Bracket – Transom Mount

Heavy duty TIG welded aluminum brackets for guiding your cajun anchor (aka shallow water anchor or spud anchor) pole.

Cajun anchors are a simple and inexpensive way to hold your boat in a shallow water fishing spot. A cajun anchor is a 3/4″ round sharpened metal bar that sticks in the mud. Our unique brackets provide a vertical guide for the poles for easy deployment and retrieval.

Standard Dimensions:

  • Guide Pipe: 8″ long x 1″ sch 40 pipe (1.315″ OD/1.05″ ID)
  • Mounting pad: 4″x3″ rectangular machined pad with 4x 1/4″ holes.
  • The guide pole is tilted 10 degrees towards the transom so it sits vertically on most raked transoms. (We can customize this angle if you have a flat transom or extreme rake).
  • Machined Delrin liner bushing is included.

Options:

  • Large 1-1/4″ (1.66″ OD/1.38″ ID) guide pipe for larger diameter fiberglass anchors
  • Extra large 1-1/2″ (1.9″ OD/1.61″ ID) guide pipe for 1″ sch 40 pipe push poles and spud poles.
  • Double-barrel w/ 1 closed end pipe for holstering.
  • Powder coating

$110.00

The lead time for this product is approximately 1 weeks

Guide Pipe Size *

The smaller guide pipe is suitable for 3/4″ metal anchor pins. Many fiberglass 2 piece poles require the larger guide pipe due to the size of the connecting fittings.

Finish *

Choose bare aluminum, brushed anodized, or powder coating. Note: powder coating will add 2 weeks to lead time.

Single or Double Barrel *

The double barrel has a second guide pipe which is closed at the end so you don’t have to get mud in your boat on retrieval. Just drop the anchor pole in the closed pipe and ride to the next spot. Note: we don’t recommend high speed travel, rough water, or trailering with the anchor in the bracket.

We can include a fastener kit for installing your bracket. All fasteners are 316 stainless steel. Backing plates are 1/8″ aluminum plate matching the hole pattern on your bracket.

SKU: SWB-T Category: Tags: , ,
